RICH SOLAR is the leading supplier of off-grid solar equipment for RV, agriculture, off-grid housing, marine equipment since 2005.

Features:

Maintenance Free

Manufactured with thick absorbent glass mat (AGM) separators and advanced valve regulated technology, RICH SOLAR Deep Cycle AGM Batteries save you from acid leakage and frequent maintenance

Excellent Discharge Performance

Proprietary quinary alloy plates and specially treated plate grids enable low internal resistance and high discharge currents of up to 10 times the battery rated capacity

Long Shelf Life

Made of high purity materials, RICH SOLAR Deep Cycle AGM Batteries reduce the monthly self-discharge rate below 3% at 77°F, which is 5 times lower than their flooded counterparts

Wide Operation Temperature Range

Improved electrolyte formula ensures stable battery capacity and outstanding discharge performance at low temperatures below 32°F (0°C).

Tips:

• To avoid cycle life shortening, it is recommended not to discharge the battery below 50%.
• It is highly recommended to use a battery balancer to extend the battery service life when multiple batteries are connected in series and/or in parallel.

Specifications:

Electrical

• Battery Type: AGM
•

• Rated Capacity: 200Ah (20 Hour Rate to 10.5V)
•

• Nominal Voltage: 12V
•

• Cycle Use Voltage: 14.4V~14.8V
•

• Internal Resistance: Approx. 3.5mΩ
•

• Self-discharge Rate (77°F): ＜3% / month
•

• Connection Method: In Series, and In Parallel (up to 4)
•

• Automatically Self-heating Function: No

Mechanical

• Dimensions: 20.6 x 9.4 x 8.8 in
• Weight: 127.9 lb
• Container Material: ABS

Charging Parameters

• Float Charge Voltage: 13.6V~13.8V
• Maximum Charging Current: 60A

Discharging Parameters

• Maximum Discharging Current: 2000A (5 seconds)

Temperature Parameters

• Standard Operation Temperature: 77°F±9°F
• Storage Temperature: -4~140°F
• Charge Temperature: 32~122°F
• Discharge Temperature: -4~140°F

Accessories

• M8 Bolts: x2

Warranty

• Material and workmanship warranty: 2 years

Certifications

• MSDS: Yes
